Sensor & Size | 1080P/5M/ Sony IMX178(C) 1/1.8"(6.22x4.67) | 1080P/2M/ Sony IMX185(C) 1/1.9"(7.20x4.05) | 1080P/2M/ Sony IMX249(C,GS) 1/1.2"(11.25x6.33) |
Pixel(μm) | 2.4x2.4 | 3.75x3.75 | 5.86x5.86 |
G Sensitivity Dark Signal | 425 mv with 1/30s 0.15 mv with 1/30s | 1120 mv with 1/30s 0.15 mv with 1/30s | 1016 mv with 1/30s 0.15 mv with 1/30s |
FPS/Resolution | 60@1920x1080 (HDMI) 25@1920x1080 (WIFI) | 60@1920x1080 (HDMI) 25@1920x1080 (WIFI) | 60@1920x1080 (HDMI) 25@1920x1080 (WIFI) |
Binning | 1x1 | 1x1 | 1x1 |
Exposure | 0.03ms~918ms | 0.06ms~918ms | 0.043ms~1000ms |
Interface & Button Functions | |||
|---|---|---|---|
| USB | USB Camera or USB Mouse | ||
| HDMI | HDMI Output | ||
| DC12V | 12V Power in | ||
| SD | SD Card Slot | ||
| ON/OFF | Power On/Off Switch | ||
LED | Power On Indicator | ||
Other Specification for HDMI Output | |||
| UI Operation | With USB Mouse | ||
| Image Capture | JPEG Format with 5M Resolution in SD Card JPEG Format with 2M Resolution in SD Card | ||
| Video Record | ASF Format 1080P 30fps in SD Card | ||
| Camera Control Panel | Including Exposure, Gain, White Balance, Color Adjustment, Sharpness and Denoising Control | ||
| Toolbar | Including Zoom, Mirror, Comparison, Freeze, Cross, Browser Function | ||
Other Specification for WIFI Output | |||
| UI Operation | With USB Mouse to Operate on the embedded XCamView | ||
| WIFI Performance | 802.11n 150Mbps; RF Power 20dBm(Maximum) | ||
| Maximum Connected Devices | 3~6(According to the Environment and Connection Distance) | ||
| White Balance | Auto White Balance | ||
| Color Technique | Ultra-Fine Color Engine (WIFI) | ||
| Capture/Control API | Standard SDK for Windows/Linux/Mac(WIFI) | ||
| Recording System | Still Picture or Movie (WIFI) | ||
Software Environment (for USB2.0 Connection) | |||
| Operating System | Microsoft® Windows® XP /Vista /7/8/8.1/10(32 & 64 bit) OSx(Mac OS X) Linux | ||
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher | ||
| Memory: 4GB or More | |||
| USB Port: USB2.0 High-speed Port | |||
| Display: 19” or Larger | |||
| CD-ROM | |||
Operating Environment | |||
Operating Temperature | -10~50(in Centidegree) | ||
| Storage Temperature | -20~60(in Centidegree) | ||
| Operating Humidity | 30~80%RH | ||
| Storage Humidity | 10~60%RH | ||
| Power Supply | DC 12V/2A Adaptor | ||
Overall Dimensions | |||
| Width x Depth x Height | 78 mm (3.07”) x 70 mm (2.76”) x 92mm (3.62”) | ||
| Shipping Weight | 0.47 kg (1.0lbs) | ||
