A12.0904 Laboratory Microscope | A | B | |
|---|---|---|---|
| Optical System | Color Corrected Infinity Optical System | ||
Head | Binocular, 30° Inclinded, 360° Rotatable, Interpupillary Distance 54~75mm, Diopter Adjustable +/-5° | o | |
| Trinocular, 30° Inclinded, 360° Rotatable, Interpupillary Distance 54~75mm, Diopter Adjustable +/-5° | o | ||
Eyepiece | PL10x/22m, High Eyepoint, With Eye-cup | ||
| Nosepiece | Reversed Quintuple Nosepiece | ||
| Objective | Infinity Plan Achromatic Objectives 4x/0.1, W.D. 7.18mm 10x/0.25, W.D. 4.70mm 20x/0.40, W.D. 1.75mm 40x/0.65, W.D. 0.72mm 100x/1.25 W.D. 0.15mm | ||
| Working Stage | Double Layer Mechanical Stage, 175*145mm, Moving Range 75*50mm, Moving Precision 0.1mm | ||
| Focusing | Low Position Coaxial Focusing System, WIth Tension Adjustment and Up-limit. Coarse Focusing Range 25mm, Fine Focusing Precision 0.002mm | ||
| Condenser | N.A.1.2/0.22 Swing Achromatic Condenser, With Scale Marked Diaphragm | ||
| Illumination | Built-in Koehler Illumination 6V30W Halogen Light (Philips 5761), Brightness Continously Adjustable, Center Pre-fixed | ||
| Filter | Blue Filter Dia.45mm | ||
| Power | 90~240V Wide Range Voltage | ||
| Stand | Ergonomic Design, The Inverted"Y"Shape, Support Microscope Extra Lateral Stability | ||
A12.0904 Laboratory Microscope Optional Accessories | Item No. | ||
| Eyepiece | PL10x/22m, High Eyepoint | A51.0903-1516 | |
| PL10x/22r, Plan Eyepiece with Cross, High Eyepoint | A51.0905-1022r | ||
| Dark Field | Dark Field Condenser, Dry, N.A=0.9 | A5D.0912-D | |
| Dark Field Condenser, Immersion, N.A=1.2 | A5D.0912-W | ||
| A5C.0905-IPInfinity Plan Phase Contrast Set | Centering Telescope | A5C.0910-30 | |
| Infinity Plan Phase Contrast Objective 10x/0.25, W.D. 4.70mm | A5C.0636-10 | ||
| Infinity Plan Phase Contrast Objective 20x/0.25, W.D. 1.75mm | A5C.0636-20 | ||
| Infinity Plan Phase Contrast Objective 40x/0.65, W.D. 0.72mm | A5C.0636-40 | ||
| Infinity Plan Phase Contrast Objective 100x/1.25, W.D.0.15mm | A5C.0636-100 | ||
| Infinity Phase Contract Disc Condenser, Abbe N.A.1.25 | A5C.0912-PCI | ||
| Polarizing Set | Polarizer, Dia. 45mm | A5P.0917-P | |
| Analyizer Slide | A5P.0917-A | ||
| λ Slide | A5P.0917-C1 | ||
| Rotatable Working Stage | A5P.0917-RW | ||
| Upgrade to A15.0901 Polarizing Microscope Upgrade to A15.0902 Polarizing Microscope | |||
| Fluorescent | Upgrade to A16.0902 Fluorescence Microscope, APO Upgrade to A16.0903 Disc Fluorescence Microscope, APO | ||
| Metallurgical | Upgrade to A13.0904 Metallurgical Microscope | ||
| Digital | Upgrade to A31.0904 Digital Laboratory Microscope | ||
| Filter | Yellow, Dia.45mm | A56.0935-XYY | |
| Green, Dia.45mm | A56.0935-XYG | ||
| Neutral, Dia.45mm | A56.0935-XYF | ||
| Adapter | C-Mount, 1.0x, Focus Adjustable | A22..0926-10 | |
| C-Mount, 0.67x, For 2/3"CCD, Focus Adjustable | A22..0926-67 | ||
| C-Mount, 0.50x, For 1/2"CCD, Focus Adjustable | A22..0926-50 | ||
| C-Mount, 0.35x, For 1/3"CCD, Focus Adjustable | A22..0926-35 | ||
