SpecificationA13.1012 | A | B |
Head | Seidentopf trinocular viewing head, inclined at 30°, interpupillarty distance 55-75mm |
Eyepiece | WF10×/ 18 |
| WF10×/ 18 with 0.1mm Micrometer and Cross Hair |
Infinity
Plan Achromatic Objective | 4×/ 0.1/ ∞/ - (Bright Field use) |
| 10×/ 0.25/ ∞/ - (Bright/ Dark Field use) |
| 20×/ 0.40/ ∞/ - (Bright/ Dark Field use) |
| 40×/ 0.65/ ∞/ 0 (Bright Field use) |
| 80×/ 0.90/ ∞/ 0 (Bright Field use) |
| 40×/ 0.65/ ∞/ 0.17 (Spring) (Biological use) | | ● |
| 100×/ 1.25/ ∞/ 0.17 (Spring、Oil) (Biological use) | | ● |
Stage | Double Layer Mechanical Stage 185×142mm/75×55mm, Nonius reading up to 0.1mm |
| Specimen Preparation Plate |
Nosepiece | Quintuple nosepiece (3 holes for bright field objective use, 2 holes for dark field objective use) |
Polarization System | Built-in polarizer and Analyzer |
Bright/Dark Viewing Field System | Built-in Conversion Slide for Bright/dark Field Illumination |
Object Micrometer | 0.01mm used with Micrometer Eyepiece for Calibration |
Diaphragm | Epi-illuminator with Iris Aperture Diaphragm and Iris Field Diaphragm |
Reflected Illumination | 12V/ 50W Halogen light, lightness adjustable |
Filter | Blue |
| Green |
| Yellow |
Condenser | N.A.1.25 Abbe condenser with Iris diaphragm & filter holder & blue filter (Biological use) | | ● |
Collector | Center adjustable kohler collector with field iris diaphragm (Biological use) | | ● |
Polarizer | Placed on collector and used with Analyzer under Trinocular Head (Biological use) | | ● |
Transmitted
Illumination | 12V/ 20W Halogen light, lightness adjustable (Biological use) | | ● |
