OPTO-EDU A17.1026-B 3 Head Multi Viewing Microscope Dual Viewing Microscope

A17.1026-B

Like Favorites

OPTO-EDU A17.1026-B 3 Head Multi Viewing Microscope Dual Viewing Microscope


Quantity:

A17.1026-B Multi-Viewing Microscope, 3 Position
Optical System
lnfinite Optical System
Head

1 pcs Trinocular Head, 30°Inclined, 360° Rotatable, Interpupilary Distance 48-75mm
2 pcs Brinocular Head, 30°Inclined, 360° Rotatable, Interpupilary Distance 48-75mm

Eyepiece

WF10X, 6 pcs

Objective
Infinity Plan Achromatic 4x, 10x, 40x(s), 100x(s, oil)
Nosepiece
Reversed Quadruple Revolving Nosepiece
Stage
Double Layers Mechanical Stage 185x142mm, Moving Range 75x55mm
Focusing
Coaxial Coarse & Fine Focusing Knobs, Fine division 0.002mm

Condenser

Swing Abbe Condenser N.A.0.9/0.25
Light Source
External Kohler Illumination, Halogen Lamp 12V50W
PointerGreen LED Pointer, Brightness Adjustable
A17.1026-B Multi-Viewing Microscope, Optional Accessories
Adapter1.0x C-Mount A55.1002-10
0.5x C-Mount A55.1002-05
