WIFI Microscope, 200X,0.3M,WinXP/Vista/7
WIFI Microscope, 200X,0.3M,WinXP/Vista/7
WIFI Microscope, 200X,0.3M,WinXP/Vista/7

A34.4180

Like Favorites

WIFI Microscope, 200X,0.3M,WinXP/Vista/7

Quantity:

This model break the limitation of distance,it works within 10 meter's range without any wire! Equipped with measurement software and can tell simple measure data conveniently.
It can be  easily used in different fields including:

  1.Textile  industrial for textile inspection
  2.Printing inspection
  3.Industrial inspection:PCB,Pricision machinery
  4.Educational Purpose
  5.Hair Examination
  6.Skin Examination
  7.Microbiological Obervation
  8.Jewerly&Coin(Colletions)inspection
  9.Visual Assistance


A 34.4180 Specification
Magnification5 X ~ 200X ( Manual )
Focus Range0mm ~40mm
Image SensorCMOS Sensor
SoftwareSnap Shot Software
Frequency2.4GHZ
ResolutionVideo Capture Resolution 0.3M
Still Image Capture Resolution 640*480
ControllerHigh Speed DSP(Driver Free Available)
Frame Rate 25f/s VGA under 600 lux brightness
20f/s QVGA under 600 lux brightness
Power SupplyTX Rechargeable Lithium Battery,RX 5V DC from USB port, USB2.0&1.1 compatible
IlluminationBuilt-in 4-8 White-light LED and adjustable illumination ensure the magnified images are clear and bright,brightness control manual adjustment.
Operation SystemWindows XP,Vista, Win7 32bit and 64bit
System RequirementPentium Computer with 700M Hz & Above , 20M HD Space CD ROM Driver, 64MB RAM , Direct X VGA Card
LanguageEnglish,Chinese and other language by selection
DriverCD Disk Driver and micro-Measurement Tool
Dimension142mm(L)*37mm(R)
Net Weight100g
ColorIron Gun Colors
