Metallurgical Microscope
Metallurgical Microscope

A13.0710

Like Favorites

Metallurgical Microscope

Quantity：


A13.0710
Model
B
BD
Head

Trinocular Head

Trinocular Head

EyepieceEW10X/22 Φ30

Nosepiece

Five Holes

5X/0.12/∞/-(BF) LWD 15.5mm
10X/0.25/∞/-( BF) LWD 10mm
20X/0.4/∞/0(BF)  LWD 5.8mm
50X/0.75/∞/0(BF) LWD 0.32mm
100X/0.8/∞/0(BF) LWD 2mm		5X/0.12/∞/-( BF/DF)  LWD 12mm
10X/0.25/∞/-( BF/DF)  LWD 10mm
20X/0.4/∞/0(BF/DF)  LWD 4.3mm
50X/0.75/∞/0(BF/DF) LWD 0.32mm
100X/0.8/∞/0(BF/DF)  LWD 2mm
BaseBase 396X276X22mm, Column Height 300mm,Column Diameter 30mm
FocusingCoarse And Fine Motion Coaxial Focusing. Fine Adjustment Value 1μm, Coarse And Elastic Adjustment, With Limit Device, Moving Range 32mm
