Zoom Stereo Microscope, 0.7-4.5x, Binocular
Zoom Stereo Microscope, 0.7-4.5x, Binocular
Zoom Stereo Microscope, 0.7-4.5x, Binocular
Zoom Stereo Microscope, 0.7-4.5x, Binocular
Zoom Stereo Microscope, 0.7-4.5x, Binocular
Zoom Stereo Microscope, 0.7-4.5x, Binocular
Zoom Stereo Microscope, 0.7-4.5x, Binocular
Zoom Stereo Microscope, 0.7-4.5x, Binocular

A23.1502-B1

Like Favorites

Zoom Stereo Microscope, 0.7-4.5x, Binocular


  • Zoom Stereo 0.7x~4.5x, Total Magnification Up To 3.5x~180x With Auxiliary Lens & Eyepiece
  • Trinocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable
  • Wide Field Plan Eyepiece WF10x/20mm, WF15x, WF20x Optional
  • Auxiliary Lens 0.5x, 0.75x, 2.0x Optional To Enlarge Magnfication and Working Distance
  • Large Pole Stand With Up/Bottom LED Light In Square & Fan Shape For Choice
Quantity:





A23.1502 Zoom Stereo MicroscopeB1T1B31T31B32T32
HeadBinocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mmo o o
Trinocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm, With Eyepiece Adatper + 1.0x C-Mount o o o
Magnification7x-45x, Up to 3.5x-180x With Optional Eyepieces & Auxiliary Objectives
EyepieceWF10x/20mm, High Eyepoint
Zoom Lens0.7~4.5x
Zoom Ratio1:6.5
Working Distance100mm, Up To 30~177mm With Auxiliary Objectives
Field of View1~95.2mm
FocusingCoarse Focusing Knob
Light SourceNo Lightoo
Upper/Bottom LED, Brightness Adjustable  oooo
StandST1 Square Base Pole Stand, Height 248mm, Base 200*255*22mmoo
BL3 Big Fan Base Pole Stand, With Up/Bottom LED  oo
BL3 Big Square Base Pole Stand, With Up/Bottom LED    oo
A23.1502 Zoom Stereo Microscope Optional AccessoriesCata. No.
EyepieceWF15x/15mm, High-EyepointA51.1520-15
WF20x/10mm, High-EyepointA51.1520-20
Auxiliary Lens0.5x,W.D. 177mmA52.1520-05
0.75x,W.D. 120mmA52.1520-75
2.0x,W.D. 30mmA52.1520-20
CCD AdapterEyepiece Adatper + 0.5x C-MountA55.1520-05
Pictures
Model No. A23.1502-B1 A23.1502-T31 A23.1502-T32
Features
DIC (Differential Interference Contrast) DIC (Differential Interference Contrast) DIC (Differential Interference Contrast)
New Product Year
2017 2017 2017
Optical System
Key Feature, 只写最重要的几条特征, 展示在对比界面 Key Feature, 只写最重要的几条特征, 展示在对比界面 Key Feature, 只写最重要的几条特征, 展示在对比界面
Standard Magnification
7x 10x 10x
Optional Magnification
45x 100x 100x
Head Type
Sedentopf Binocular —— ——
Head Inclination
45° —— ——
Head Rotation
360° —— ——
Head Interpupillary
54~75mm —— ——
Head Diopter
Diopter Adjustable_Both Tube —— ——
Head Light Path
180x 100x 100x
Eyepiece Features
Wide Field —— ——
Eyepiece Diameter
2 —— ——
Working Distance
格式:1.0,或1.0~2.0 格式:1.0,或1.0~2.0 格式:1.0,或1.0~2.0
Working Stage Type
Round —— ——
Working Stage Feature
Ergonomic Low Position Stage Knob Ergonomic Low Position Stage Knob Ergonomic Low Position Stage Knob
Working Stage Size
Dia.125 格式:100x100mm,或 Dia.100mm 格式:100x100mm,或 Dia.100mm
Focusing Type
Coaxial Coarse & Fine Focus Coaxial Coarse & Fine Focus Coaxial Coarse & Fine Focus
Focusing Range
0.000000 0.000000 0.000000
Focusing Scale
0.000000 0.000000 0.000000
Light Source Type
None —— ——
Transmit Light
None —— ——
Camera Output
C-Mount C-Mount C-Mount
