Binocular Zoom Stereo Microscope, 0.7x~4.5x, Pole Stand,Up & down LED

A23.1502-B31

Like Favorites

Binocular Zoom Stereo Microscope, 0.7x~4.5x, Pole Stand,Up & down LED

Zoom Stereo 0.7x~4.5x, Total Magnification Up To 3.5x~180x With Auxiliary Lens & Eyepiece
Trinocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable
Wide Field Plan Eyepiece WF10x/20mm, WF15x, WF20x Optional
Auxiliary Lens 0.5x, 0.75x, 2.0x Optional To Enlarge Magnfication and Working Distance
Large Pole Stand With Up/Bottom LED Light In Square & Fan Shape For Choice

A23.1502 Zoom Stereo Microscope Optical Data Sheet
Objective	Standard 1.0x		Auxiliary 0.5x		Auxiliary 0.75x		Auxiliary 2.0x
W,D.	100mm		177mm		120mm		30mm
Eyepiece	Mag	View Field	Mag	View Field	Mag	View Field	Mag	View Field
10X/20mm	7.0X	28.6mm	3.5X	57.1mm	5.25x	43.8mm	14X	14.3mm
	45.0X	4.4mm	22.5X	8.9mm	45x	6.5mm	90X	2.2mm
15X/15mm	10.5X	21.1mm	5.25X	42.8mm	7.87x	31.8mm	21X	10.7mm
	67.5X	3.3mm	33.75X	6.7mm	50.6x	4.7mm	135X	1.7mm
20X/10mm	14.0X	14.3mm	7.0X	28.6mm	10.5x	23.9mm	28X	7.1mm
	90.0X	2.2mm	45.0X	4.4mm	67.5x	3.6mm	180X	1.1mm

A23.1502 Zoom Stereo Microscope		B1	T1	B31	T31	B32	T32
Head	Binocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm	o		o		o
Head	Trinocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm, With Eyepiece Adapter + 1.0x C-Mount		o		o		o
Magnification	7x-45x, Up to 3.5x-180x With Optional Eyepieces & Auxiliary Objectives
Eyepiece	WF10x/20mm, High Eyepoint
Zoom Lens	0.7~4.5x
Zoom Ratio	1:6.5
Working Distance	100mm, Up To 30~177mm With Auxiliary Objectives
Field of View	1~95.2mm
Focusing	Coarse Focusing Knob
Light Source	No Light	o	o
Light Source	Upper/Bottom LED, Brightness Adjustable			o	o	o	o
Stand	ST1 Square Base Pole Stand, Height 248mm, Base 20025522mm	o	o
	BL3 Big Fan Base Pole Stand, With Up/Bottom LED			o	o
	BL3 Big Square Base Pole Stand, With Up/Bottom LED					o	o
A23.1502 Zoom Stereo Microscope Optional Accessories		Cata. No.
Eyepiece	WF15x/15mm, High-Eyepoint	A51.1520-15
Eyepiece	WF20x/10mm, High-Eyepoint	A51.1520-20
Auxiliary Lens	0.5x,W.D. 177mm	A52.1520-05
	0.75x,W.D. 120mm	A52.1520-75
	2.0x,W.D. 30mm	A52.1520-20
CCD Adapter	Eyepiece Adapter + 0.5x C-Mount	A55.1520-05

Pictures
Model No.	A23.1502-B31
Working Distance	格式:1.0,或1.0~2.0
Video Adapter	C-Mount 0.3x
Focusing Scale	0.000000
Focusing Range	0.000000
Working Stage Size	格式:100x100mm,或 Dia.100mm
New Product Year	2017
