A23.1502-B32

Like Favorites

Zoom Stereo Microscope

Zoom Stereo 0.7x~4.5x, Total Magnification Up To 3.5x~180x With Auxiliary Lens & Eyepiece
Trinocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable
Wide Field Plan Eyepiece WF10x/20mm, WF15x, WF20x Optional
Auxiliary Lens 0.5x, 0.75x, 2.0x Optional To Enlarge Magnfication and Working Distance
Large Pole Stand With Up/Bottom LED Light In Square & Fan Shape For Choice

A23.1502 Zoom Stereo Microscope		B1	T1	B31	T31	B32	T32
Head	Binocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm	o		o		o
Head	Trinocular Head, 45° Inclined, 360° Rotatable, ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm, With Eyepiece Adatper + 1.0x C-Mount		o		o		o
Magnification	7x-45x, Up to 3.5x-180x With Optional Eyepieces & Auxiliary Objectives
Eyepiece	WF10x/20mm, High Eyepoint
Zoom Lens	0.7~4.5x
Zoom Ratio	1:6.5
Working Distance	100mm, Up To 30~177mm With Auxiliary Objectives
Field of View	1~95.2mm
Focusing	Coarse Focusing Knob
Light Source	No Light	o	o
Light Source	Upper/Bottom LED, Brightness Adjustable			o	o	o	o
Stand	ST1 Square Base Pole Stand, Height 248mm, Base 20025522mm	o	o
	BL3 Big Fan Base Pole Stand, With Up/Bottom LED			o	o
	BL3 Big Square Base Pole Stand, With Up/Bottom LED					o	o
A23.1502 Zoom Stereo Microscope Optional Accessories		Cata. No.
Eyepiece	WF15x/15mm, High-Eyepoint	A51.1520-15
Eyepiece	WF20x/10mm, High-Eyepoint	A51.1520-20
Auxiliary Lens	0.5x,W.D. 177mm	A52.1520-05
	0.75x,W.D. 120mm	A52.1520-75
	2.0x,W.D. 30mm	A52.1520-20
CCD Adapter	Eyepiece Adatper + 0.5x C-Mount	A55.1520-05

Pictures
Model No.	A23.1502-B32
Features	DIC (Differential Interference Contrast)
New Product Year	2017
Optical System	Key Feature, 只写最重要的几条特征, 展示在对比界面
Standard Magnification	10x
Optional Magnification	100x
Head Light Path	100x
Working Distance	格式:1.0,或1.0~2.0
Working Stage Feature	Ergonomic Low Position Stage Knob
Working Stage Size	格式:100x100mm,或 Dia.100mm
Focusing Type	Coaxial Coarse & Fine Focus
Focusing Range	0.000000
Focusing Scale	0.000000
Camera Output	C-Mount
