Zoom Stereo Microscope, Mobile Phone Repair

A23.3645N-R2

Like Favorites

Zoom Stereo Microscope, Mobile Phone Repair

38M HDMI+USB Digital Camera
0.7~4.5x High Quality Optical System Zoom Stereo Microscope
Trinocular Head Light Split 5:5 Support View Image In Eyepiece & LCD At Same Time
Upper 56 LEDs Right Light Brightness Adjustable
Large Alloy Soft Pad Working Area For Phone Repair

Specification:

Digital Zoom Stereo Microscope, Mobile Phone Repair

A23.3645N-R2-H1

A23.3645N-R2

LCD Digital Zoom Stereo Microscope, Mobile Phone Repair

A23.3645N-R2-L1

A23.3645N-R2 Series DIY Phone PCB Repair Microscope		A23.3645N- R2	A23.3645N- R2L1	A23.3645N- R2H1
Head	Trinocular Head, With Eyepiece Adapter	●
	LCD Screen 9"With Digital Camera, AV Output		●
	HDMI+USB Digital Camera 38.0M Pixels			●
	45° Inclined, 360°Rotatable, Both Tube ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm
Eyepiece	WF10x/20mm, Both With Eye-cup
Zoom Lens	0.7~4.5x
Zoom Ratio	1:6.5
Magnification	7x-45x, Up To 3.5x-180x With Optional Eyepieces And Auxiliary Lens
W.D.	Working Distance100mm, With Standard 1x Lens
F.O.V	Field Of View 1~95.2mm
Stand	Large Pole Stand, Size 2002558mm, Pole Height 240mm, Dia.32mm, With Heat Resist Soft Rubber Pad, Working Area For Phone PCB Repair
Light Source	Upper 56 LEDs Right Light Brightness Adjustable
Optional Accessories			Cata.No.
Eyepiece	WF15x/15mm, High-eyepoint		A51.3621-1515
	WF20x/10mm, High-eyepoint		A51.3621-2010
	WF25x/9mm, High-eyepoint		A51.3621-2509
	WF30x/8mm, High-eyepoint		A51.3621-3008
Auxiliary Lens	0.5X,W.D. 165mm		A52.3621-0.5x
	1.5X,W.D. 45mm		A52.3621-1.5x
	2.0X,W.D. 30mm		A52.3621-2.0x

Pictures Hide Same Show Difference
Model No.	A23.3645N-R2	A23.3645N-R2-H1
Camera Output	VGA/RCA	VGA/RCA
Camera Mounting	Eyepiece Tube	Eyepiece Tube
Camera Screen Size	9”	9”
Stereo Stand	Stand 20025522mm, Pole Height 240mm, Dia.32mm	Stand 20025522mm, Pole Height 240mm, Dia.32mm
Stereo Stand Type	Pole Stand	Pole Stand
Working Distance	100mm, With Auxiliar	100mm, With Auxiliar
Stereo Zoom Ratio	1:6.25	1:6.25
Reflect Light	56 LEDs Right Light Brightness Adjustable	56 LEDs Right Light Brightness Adjustable
Light Source Type	LED	LED
Working Stage	Soft Pad Working Area	Soft Pad Working Area
Objective	0.7x~4.5x	0.7x~4.5x
Eyepiece	WF10x/20mm, 2 pcs	WF10x/20mm, 2 pcs
Eyepiece Diameter	30.0mm	30.0mm
Head Rotation	Head Rotate 360°	Head Rotate 360°
Head Type	Seidentopf Trinocular	Seidentopf Trinocular
Optical System	Greenough	Greenough
New Product Year	2018	2018
