A12.1303-V

Like Favorites

Laboratory Microscope, Dual Teaching

  • Total Magnification 40x-1000x, Up To 40x-2500x With Optional Eyepieces
  • Monocular, Dual View, Binocular, Trinocular Heads Available For Photo Video Capture
  • Achromatic Objective 4x, 10x, 40x, 100x On 4 Holes Nosepiece
  • Double Layer Mechanical Stage 125x125mm, Moving Range 40x50mm
  • TransmitLight Source LED Brightness Adjustable
Specification:
Laboratory Microscope, Dual Teaching A12.1303-V Laboratory Microscope, Dual Viewing A12.1303-S Laboratory Microscope, Binocular A12.1303-B Laboratory Microscope, Trinocular A12.1303-T Laboratory Microscope, Monocular A12.1303-M
Quantity：









A12.1303 Biological MicroscopeMVSBT
HeadMonocular Head, 30° Inclinedo
Seidentopf Binocular Head, 30° Inclined, Interpupillary Distance 55~75mmo
Seidentopf Trinocular Head, 30° Inclined, Interpupillary Distance 50~75mm, With Digital Eyepiece Adapter, Height Adjustableo
Dual Observation Head, 30° Inclined / Verticalo
Dual Observation Head, 45° Inclinedo
EyepieceWF10x
NosepieceBackward, Quadruple Nosepiece
Objective45mm DIN Achromatic 4x,10x,40x(S),100x(O,S)
Working StageDouble Layer Mechanical Stage, Size 125*125mm, Moving Range X-Y 50*40mm
CondenserAbbe N.A.1.25, With Dia.2-Dia.30mm Iris Diaphragm,
FocusingLow Position Designed, Coaxial Coarse & Fine Focusing, Coarse Focusing Range 25mm, Fine Focusing Scale 0.002mm, With Tension Adjustment, With Upper Safety Stop
Light SourceLED Lamp
G.W.10KG
Package2 Sets/Carton










Pictures
Laboratory Microscope, Dual Teaching
Laboratory Microscope, Monocular
Laboratory Microscope, Dual Viewing
Laboratory Microscope, Binocular
Laboratory Microscope, Trinocular
Model No. A12.1303-V A12.1303-M A12.1303-S A12.1303-B A12.1303-T
Power Supply Type
 AC 100V-240V Wide Voltage AC 110V-240V AC 100V-240V Wide Voltage AC 100V-240V Wide Voltage AC 100V-240V Wide Voltage
Transmit Light
 LED LED LED LED LED
Light Source Type
 LED LED LED LED LED
Light Source Features
 Brightness Adjustable —— Brightness Adjustable Brightness Adjustable Brightness Adjustable
Condenser
 With Dia.2-Dia.30mm Iris Diaphragm With Dia.2-Dia.30mm Iris Diaphragm With Dia.2-Dia.30mm Iris Diaphragm With Dia.2-Dia.30mm Iris Diaphragm With Dia.2-Dia.30mm Iris Diaphragm
Condenser N.A.
 1.25 1.25 1.25 1.25 1.25
Condenser Type
 Abbe Abbe Abbe Abbe Abbe
Condenser Features
 With Filter Holder
Rack & Pinion Up/Down		 Center Adjustable
Iris Diaphragm
Rack & Pinionↆ↑		 With Filter Holder
Rack & Pinion Up/Down		 With Filter Holder
Rack & Pinion Up/Down		 With Filter Holder
Rack & Pinion Up/Down
Focusing Scale
 0.002mm 0.002mm 0.002mm 0.002mm 0.002mm
Focusing Range
 25mm 25mm 25mm 25mm 25mm
Focusing Type
 Coaxial Coarse & Fine Coaxial Coarse & Fine Coaxial Coarse & Fine Coaxial Coarse & Fine Coaxial Coarse & Fine
Focusing Features
 Safety Stop Screw Safety Stop Screw Safety Stop Screw Safety Stop Screw Safety Stop Screw
Working Stage Moving
 50x40mm 50x40mm 50x40mm 50x40mm 50x40mm
Working Stage Size
 125x125mm z125x125mm 125x125mm 125x125mm 125x125mm
Working Stage Type
 Double Layers Mechanical 2 Layers Mechanical Double Layers Mechanical Double Layers Mechanical Double Layers Mechanical
Objective
 Achromatic 4x, 10x, 40x(s), 100(s,o) Achromatic 4x, 10x, 40x(s), 100(s,o) Achromatic 4x, 10x, 40x(s), 100(s,o) Achromatic 4x, 10x, 40x(s), 100(s,o) Achromatic 4x, 10x, 40x(s), 100(s,o)
Objective Type
 Achromatic Achromatic Achromatic Achromatic Achromatic
Nosepiece Holes
 4 Holes 4 Holes 4 Holes 4 Holes 4 Holes
Eyepiece
 —— WF10x —— —— ——
Eyepiece Diameter
 23.2mm 23.2mm 23.2mm 23.2mm 23.2mm
Head Rotation
 Head Rotate 360° Head Rotate 360° Head Rotate 360° Head Rotate 360° Head Rotate 360°
Head Inclination
 30°+90° 30° 45°+45° 30° 30°
Head Type
 Dual-View Monocular Dual-View Seidentopf Binocular Seidentopf Trinocular
Max Magnification
 40x-1600x —— 40x-1600x 40x-1600x 40x-1600x
Standard Magnification
 40x-1000x 40x-1000x 40x-1000x 40x-1000x 40x-1000x
Optical System
 Achromatic Achromatic Achromatic Achromatic Achromatic
Function
 BF —— BF BF BF
Nosepiece Features
 —— Inward —— —— ——
Standard Function
 —— BF —— —— ——
New Product Year
 —— 2022 —— —— ——
Head Interpupillary
 —— —— —— 55~75mm 55~75mm
Video Adapter
 —— —— —— —— Digital Eyepice 23.2mm
